Scrubber, tanks and ducts to w-t-e plant

Scrubbers 2 pcs
Ø 7500/6000 mm, height 34 090 mm.
Design temp: +80 ºC (peak 95 ºC 2h /24h). Design pressure: -9kPa / +3kPa

AFM scrubbers 2 pcs
Ø 4500 mm, height 17 586 mm.
Design temp: +75 ºC (peak 95 ºC 2h/24h). Design pressure: -12,5kPa / +3kPa

Tanks 2 pcs
Ø 7500 mm, height 5950 mm. Design temp: + 80 ºC

Stack
Ø 2400 mm, height 66 000 mm. Design temp: + 80 ºC

Stack
Ø 2400 mm, height 58 000 mm. Design temp: + 80 ºC

Ducts from ID Fan to Stack
Ø 2900 mm, length 160 m. Design temp: + 80 ºC.
Design pressure: -0,5kPa /+2 kPa

Ducts from eco to quench 2 pcs
Ø 2500 mm, height 794 mm. Design temp: + 200 ºC

Ducts from reheater to ID Fan 2 pcs
Inlet 5000 mm x 2700 mm, outlet 2180 mm x 1168 mm, length 8550 mm.
Design temp: + 80 ºC. Design pressure: -9kPa/+3kPa

Ducts from Scrubber G3 to AFM 2 pcs
Inlet/outlet Ø 2900 mm, length 18 190 mm.
Design temp: + 80 ºC. Design pressure: -12,5kPa /+3 kPa

Ducts from Scrubber to G2 2 pcs
Inlet/outlet Ø 2900 mm, length 11 590 mm.
Design temp: + 80 ºC. Design pressure: -9kPa/+3kPa

Silencer casings
Design temp: + 80 ºC

Droplet separators
Inlet 3000 x 5000 mm, outlet Ø 2900 mm.
Design temp: + 80 ºC. Design pressure: -9kPa/+3kPa
